MSI B450M-A PRO MAX II AMD AM4 Motherboard
- Stock: In Stock
- Brand: MSI
- Model: B450M-A PRO MAX II
0৳
Ex Tax: 0৳
Key Features
- Supported CPU: Ryzen 5000, 5000 G, 4000 G, 3000, 3000 G-Series Processors
- Supported RAM: 2x DDR4, up to 4133 (OC) MHz
- Graphics Output: 1 x HDMI, 1x DVI
- Features: 1 x M.2 Slot, Realtek 8125 2.5Gbps LAN
Specification
| Basic Information | |
| Supported CPU | Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series, 2000 G-Series and 1000 Series Desktop Processor and Athlon with Radeon Vega Graphics desktop processors Socket AM4 |
| Chipset | AMD B450 |
| Form Factor | mATX 200mmx236mm |
| Graphics | 1x HDMI Support HDMITM 1.4, maximum resolution of 4K 24Hz 1x DVI Support DVI-D, maximum resolution of 1920x1200 60Hz |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| Expansion Slots | |
| PCI | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 2.0 supports up to x1 (From Chipset) |
| Memory | |
| Maximum Memory | 64GB |
| Slots | 2 |
| Supported Memory | Memory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE) Supports Dual-Channel mode Supports non-ECC, UDIMM memory Supports ECC UDIMM memory (non-ECC mode) Supports un-buffered memory |
| Type | DDR4 |
| Connector & Ports | |
| Audio | |
| HDMI | 1x HDMI |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| LAN Port (s) | Realtek 8125 2.5Gbps LAN controller |
| RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices |
| Supported Storage | 1x M.2 M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| USB (s) | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front |
| Wireless Communication module | |
| Warranty Information | |
| Warranty | 03 Years Warranty |
Description
MSI B450M-A PRO MAX II AMD AM4 Motherboard
The MSI B450M-A PRO MAX II AMD AM4 Motherboard is a reliable and well-balanced choice for users who want a strong foundation for building a mid-range or even a performance PC. Designed in the mATX form factor, it offers excellent compatibility while saving space, making it ideal for compact gaming, office, or productivity setups. Equipped with the AMD B450 chipset, this motherboard supports a wide range of AMD processors including Ryzen 1000 to 5000 Series CPUs, ensuring great upgrade flexibility for future performance enhancements. This board supports DDR4 memory up to 64GB with speeds reaching up to 4133MHz (OC mode), allowing smooth multitasking, faster data processing, and improved system responsiveness. Whether for gaming or professional applications, its dual-channel memory architecture boosts overall performance efficiency. It integrates Realtek ALC897 7.1-Channel HD audio for clear sound output in entertainment and content creation. In terms of connectivity, the MSI B450M-A PRO MAX II offers one PCI-E x16 and one PCI-E x1 expansion slot for GPU and additional cards. Storage is ensured through a high-speed M.2 slot supporting PCIe x4 and SATA drives as well as 4 SATA ports with RAID 0/1/10 support. For display options, it features both HDMI and DVI-D ports, supporting up to 4K resolution via HDMI. With multiple USB ports including USB 3.2 Gen1 and USB 2.0 on both front and rear panels, users get flexible connectivity for peripherals. It also includes Realtek 2.5Gbps LAN for fast and stable networking. Built with durability in mind, this motherboard offers a stable power design, TPM 2.0 support, quality components, and a 3-year warranty, making it a reliable long-term investment for PC builders.
Features of MSI B450M-A PRO MAX II AMD AM4 Motherboard
- Wide CPU Support: Compatible with Ryzen 1000 to 5000 Series & Athlon processors for versatile build options.
- High-Speed Memory Support: DDR4 support up to 64GB with speeds up to 4133MHz overclocked.
- Efficient Storage Performance: 1x M.2 slot with PCIe 3.0 x4 & SATA + 4x SATA ports with RAID support.
- Enhanced Audio Output: Realtek ALC897 7.1 HD audio for clear sound quality.
- Fast Networking: Realtek 2.5Gbps LAN for smoother online experience.
- Multiple USB Ports: 4x USB 3.2 Gen1 & 6x USB 2.0 ports for device connectivity.
- Dual Display Support: HDMI and DVI-D ports with 4K (24Hz) support via HDMI.
- Compact mATX Design: Fits easily in smaller cases while maintaining performance features.
- Reliable Build Quality: TPM 2.0 support and 3-year warranty ensures long-term usability.
