| Basic Information | |
| Supported CPU | Intel Socket LGA1700 for 14th, 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
| Chipset | Intel B760 Chipset |
| Form Factor | mATX Form Factor 9.6 inch x 8.3 inch (24.4cm x 21.1cm) |
| Graphics | 1 x VGA port 1 x HDMI port |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers |
| Expansion Slots | |
| PCI | Intel 13th & 12th Gen Processors 1 x PCIe 4.0 x16 slot Intel B760 Chipset 2 x PCIe 4.0 x1 slots |
| Memory Specifications | |
| Type | DDR5 |
| Connectivity | |
| HDMI | 1 x HDMI port |
| Memory | |
| Maximum Memory | Max. 64GB |
| Slots | 2 x DIMM |
| Supported Memory | DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) |
| Connector & Ports | |
| Internal I/O Ports | Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin Chassis Fan header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 3 additional USB 2.0 ports Miscellaneous 2 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header 1 x Speaker header 1 x 10-1 pin System Panel header |
| LAN Port (s) | 1 x Realtek 2.5Gb Ethernet |
| RAID | Intel Rapid Storage Technology supports SATA RAID 0/1/5/10. |
| Supported Storage | Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* Intel 13th & 12th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel B760 Chipset M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports |
| TPM (Trusted Platform Module ) | 1 x SPI TPM header (14-1pin) |
| USB (s) | Rear USB (Total 6 ports) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A） Front USB (Total 5 ports) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 3 additional USB 2.0 ports |
| Others | |
| Bundled Software | ASUS Exclusive Software Armoury Crate - Aura Sync - Fan Xpert - Power Saving AI Suite 3 - DIGI+ VRM - PC Cleaner ASUS CPU-Z Norton 360 Deluxe (60 Days Free Trial) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode |
| Other Features | |
| Other Features | ASUS 5X PROTECTION III - DIGI+ VRM - LANGuard - Overvoltage Protection - SafeSlot Core - Stainless-Steel Back I/O ASUS Q-Design - Q-DIMM - Q-LED Core - Q-Slot ASUS EZ DIY - ProCool ASUS Thermal Solution - VRM heatsink design Aura Sync - Aura RGB header - Addressable Gen 2 headers |
| Warranty Information | |
| Warranty | 3 years warranty |
The Asus PRIME B760M-K mATX Motherboard is a feature-rich and reliable platform designed for modern PC builders looking for stability, performance, and long-term durability. Built for Intel’s latest architecture, it supports LGA1700 socket processors, including 14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron CPUs, making it an excellent choice for gaming, productivity, and everyday computing. Powered by the Intel B760 chipset, this board ensures seamless compatibility with high-speed memory, fast storage, and next-generation connectivity. With support for DDR5 memory up to 8000(OC) and a maximum capacity of 64GB, users can enjoy improved bandwidth and performance for heavy tasks like editing, gaming, and multitasking. The motherboard features two M.2 slots with PCIe 4.0 support, along with four SATA 6Gb/s ports, offering fast and flexible storage options. Expansion is simple with one PCIe 4.0 x16 slot and two PCIe 4.0 x1 slots, suitable for adding graphics cards and additional components. Connectivity is well-rounded, featuring HDMI and VGA ports, 6 rear USB ports, and 5 front USB options through headers. It also includes Realtek 2.5Gb Ethernet for faster online performance. For superior audio quality, it uses a Realtek 7.1 HD Audio Codec with dedicated PCB layers and premium capacitors. Durability is ensured through ASUS 5X Protection III technologies, protecting the board against power surges and ensuring long lifespan. RGB lovers will appreciate its Aura Sync support, along with Addressable Gen 2 and RGB headers for customization. With advanced software including Armoury Crate, AI Suite 3, and ASUS EZ Flash, assembling and managing the system becomes easier and more efficient. Overall, the ASUS PRIME B760M-K is a reliable, future-ready motherboard ideal for compact builds with strong performance and efficiency.
